| 브랜드 이름: | Sylaith |
| 모델 번호: | DX51D, DX52D, DX53D, SGCC, SPCC |
| 모크: | 1톤 |
| 가격: | 협상 가능 |
| 배달 시간: | 수량, 치수 및 처리 요구 사항에 따라 영업일 기준 7~20일 |
| 지불 조건: | 30% T/T 사전 + 70% 잔액 |
Galvanized Steel Sheets are essential materials in modern construction and manufacturing, valued for their excellent corrosion resistance, formability, and durability. Manufactured by Wuxi Sylaith Special Steel Co., Ltd. , these high-quality GI sheets feature a Z30-Z40 zinc coating on a cold-rolled steel base, ensuring reliable performance in various applications.
Our Prime Galvanized Sheets are available in grades DX51D, DX52D, SGCC, and SPCC, meeting international standards including AISI, ASTM, JIS, DIN, GB, and EN. With thickness ranging from 0.21mm to 0.50mm, mid-hard hardness, and regular spangle finish, these sheets deliver the perfect balance of strength and formability for roofing, construction, pipe making, and general fabrication.
| Attribute | Detail |
|---|---|
| Product Name | Galvanized Steel Sheet / GI Sheet |
| Type | Steel Sheet |
| Grade | DX51D, DX52D, DX53D, SGCC, SPCC |
| Standard | ASTM, AISI, JIS, DIN, GB, EN |
| Technique | Cold Rolled Based |
| Thickness | 0.21 mm – 0.50 mm (0.3-3.0 mm available) |
| Zinc Coating | Z30 – Z40 (30-275 g/m² available) |
| Hardness | Mid Hard |
| Spangle Type | Regular Spangle |
| Surface Treatment | Chromated, oiled/non-oiled, anti-fingerprint |
| Skin Pass | Yes |
| Tolerance | ±1% |
| Processing Service | Welding, Punching, Decoiling, Bending, Cutting |
| Application | Roofing, Construction, Pipe Making, Cutting Sheets, Small Tools, Corrugated Sheets, Containers, Fences |
| Certificate | ISO 9001 |
The versatility of Sylaith Galvanized Steel Sheets makes them suitable for a wide range of industries:
Corrugated roofing sheets
Wall cladding and siding
Building panels
Ceiling tiles
Welded pipes and tubes
Conduits
HVAC ductwork
Shipping containers
Storage tanks
Industrial containers
Small tools and hardware
Fencing and gates
Electrical cabinets
Automotive parts
Wave-shaped roofing panels
Industrial shelter covers
Galvanized steel sheets are produced through a combination of cold rolling and hot-dip galvanizing processes.
High-quality steel strips are cold rolled to achieve precise thickness (0.21-0.50mm) with tight tolerances (±1%) and a smooth surface finish.
The cold rolled strip is thoroughly cleaned through:
Degreasing: Removes rolling oils
Pickling: Removes iron oxides and scale
Fluxing: Prepares surface for optimal zinc adhesion
The cleaned strip passes through a bath of molten zinc at approximately 450°C. A metallurgical bond forms between the steel and zinc, creating a corrosion-resistant layer with Z30-Z40 coating.
The coated strip is cooled, allowing zinc crystals (spangles) to form. Regular spangle provides a uniform, aesthetic appearance.
A light cold rolling pass (skin pass) is applied to:
Improve surface flatness
Enhance mechanical properties
Prevent yield point elongation
Optional treatments include:
Chromated: Enhanced corrosion resistance
Oiled/Non-oiled: Rust protection during transport
Anti-fingerprint: For visible applications
Every coil undergoes rigorous testing:
Coating weight verification (Z30-Z40)
Thickness measurement (±1% tolerance)
Surface quality assessment
Mechanical property testing
A:
DX51D: European standard (EN 10346) for hot-dip galvanized steel, widely used internationally
SGCC: Japanese standard (JIS G3302) for hot-dip galvanized steel, common in Asia
Both offer excellent corrosion resistance and formability. We can supply either based on your requirements.
A: Z30-Z40 refers to the zinc coating weight of 30-40 g/m² (total both sides). This provides good corrosion resistance for general applications. Higher coating weights (up to Z275) are available for more corrosive environments.
A: Mid Hard indicates an optimal balance between strength and formability:
Hard enough for structural integrity
Soft enough for bending and forming
Ideal for general fabrication and roofing applications
A: Regular spangle refers to the visible zinc crystal pattern on the surface. It provides a uniform, aesthetic appearance commonly preferred for visible applications like roofing and wall panels.
A: Standard thickness range is 0.21mm to 0.50mm. We can also supply thicknesses from 0.3mm to 3.0mm upon request.
A: Yes, we offer custom lengths based on customer requirements. Please provide your specifications for a custom quotation.
A: Our products are ISO 9001 certified and comply with ASTM, AISI, JIS, DIN, GB, and EN standards.
A: MOQ is flexible — we accept orders starting from 1 ton. Sample orders are welcome.
A: Yes, we offer welding, punching, decoiling, bending, and cutting services to meet your specific requirements.
A:
Oiled: Thin protective oil layer to prevent white rust during storage and transport
Non-oiled: No oil coating, suitable for immediate painting or processing
A: Yes, sample orders are welcome. Please contact us to discuss sample requirements.
A: Yes, the Z30-Z40 zinc coating provides good corrosion resistance for outdoor applications like roofing and fencing. For harsh environments, higher coating weights (Z180-Z275) are recommended.
|
|
